Subframing Component: Thermal Break Pads for BK Series Brackets
Thermal break pads “thermally break” the rainscreen from the building to reduce the thermal transfer into the building.
X-TB-BK50 thermal break pads snap onto X-BK series brackets and can be used with both horiztonal and vertical systems. Use two break pads per bracket for horizontal systems and one break pad per bracket for vertical systems.
Mounting Type
Snap-fit to X-TB-BK50 series brackets.
Fastening Type
Exposed or Concealed
Depth
1/4 inch
Cladding Leveling
NA
Thermally Broken
Yes
Product Material
Polypropylene
Recommended Panel Types
- Fiber cement panels
- High Pressure Laminate (HPL) panels
- Fiber concrete (ultra high performance concrete)
- Composite stone (Steni and Petrarch brands)
Punched 4 inches on Center
No
Finish
Mill finish
X-TB-BK50 Data Sheet CAD
Thermal Break Pad Image
