Xkelex Horizontal Profiles for Panel Substructure
These Xkelex-designed horizontal profiles will help you achieve exposed and concealed horizontal rainscreen installations.
Four Profile Designs
- X-H19PF: 3/4 inch perforated Hat profile
- X-Z19PF: 3/4 inch perforated Zee profile
- X-L50: 2 inch L profile for BK bracket systems
- X-T50: 2 inch T profile for BK bracket systems
Mounting Type
Horizontal
Fastening Type
- X-H19PF: Exposed and Concealed
- X-Z19PF: Exposed and Concealed
- X-L50: Exposed
- X-T50: Exposed
Depth
- X-H19PF: 3/4 inch
- X-Z19PF: 3/4 inch
- X-L50: 2 inches
- X-T50: 2 inches
Cladding Leveling
- X-H19PF: No
- X-Z19PF: No
- X-L50: Yes
- X-T50: Yes
Thermally Broken
No
Product Material
6063-T5 Aluminum
Recommended Panel Types
- Fiber cement panels
- High Pressure Laminate (HPL) panels
- Fiber concrete (ultra high performance concrete)
- Composite stone (Steni and Petrarch brands)
Dimensions
Profiles are 120 inches (10 feet) long. Custom lengths are available.
- X-H19PF: 3/4 inch x 4 1/2 inches x 120 inches
- X-Z19PF: 3/4 inch x 3 inches x 120 inches
- X-L50: 2 inch x 1 5/8 inches x 120 inches
- X-Z50: 2 inch x 4 1/2 inches x 120 inches
Punched 4 inches on Center
- X-H19PF: Yes
- X-Z19PF: Yes
- X-L50: No
- X-T50: No
Finish
Black Powder Coating
Data Sheet: X-H19PF X-Z19PF X-L50 X-T50
CAD: X-H19PF X-Z19PF X-L50 X-T50
Horizontal Profile Images
X-H19PF Profile
X-Z19PF Profile
X-L50 Profile
